Grain Dryer H Type
The H-type circulating dryer series (H200, H225, H250, H275, H300, H320, H340, H360) is a high-efficiency grain drying equipment launched by Sansheng Agricultural Machinery Technology Co., Ltd., suitable for rice drying needs with a processing capacity of 20 to 36 tons.
Product Features:
High-Pressure Automatic Ignition: Automatically adjusts the flame intensity based on the set temperature to ensure combustion efficiency.
Hot & Cold Air Mixing Design: Helps save fuel while accelerating the drying process.
Internal Automatic Cleaning System: Reduces fire risk and keeps hot and cold air passages clear.
Patented Fan Drum Dust Removal Structure: Ensures cleaner grains after drying.
Patented Exhaust Fan Blades: Operate stably and resist dust accumulation.
Gravity-Based Grain Discharge (Optional): Enables fast discharge without electricity, saving time and energy.
Online Non-Destructive Automatic Moisture Meter: Measures moisture content for various grains to ensure drying quality.
Performance Description:
Loading Time: Depending on the model, rice loading time ranges from 38 to 72 minutes.
Unloading Time: Rice unloading time ranges from 41 to 75 minutes.
Drying Rate per Hour: When the initial grain moisture is 24%, the drying rate is approximately 0.5% to 0.7% per hour.
Power Requirements:
Rated Voltage: Three-phase, 220V or 380V.
Rated Power:
Elevator: 3 kW
Upper Auger: 1 kW
Lower Auger: 1 kW
Dust Removal Fan: 1 kW
Burner: 0.5 kW
Exhaust Fan: 15 kW
Drying Heat Source:
Burner Model: LT-30HW
Fuel Type: Diesel or Kerosene
Fuel Consumption: 20 to 35 liters per hour
Safety Features:
Equipped with multiple safety measures, including air pressure detection, overload protection, ignition failure detection, emergency stop button, and automatic burner shutdown in case of mechanical failure.
Standard Equipment:
Includes an automatic moisture meter and a touchscreen interface.
This series of grain dryers is ideal for medium to large farms or grain processing enterprises, providing an efficient, energy-saving, and safe grain drying solution.
