57-Inch 3-Blade EC Motor Industrial Duct Exhaust Fan
Product introduction and features
1.High-strength X-shaped stand with excellent structural grip ensures motor stability and vibration-free fan operation.
2.The wheel disc is made of aluminum alloy material, providing rust resistance and enhanced safety.
3.The front metal protective grille enhances safety levels.
4.The stand is made of aluminum alloy , offering rust and corrosion resistance, durability, and aesthetics. 5.It also prevents rainwater from flowing into the motor through the stand.
6.The entire unit uses 304 stainless steel screws.
7.Equipped with an EC motor featuring an IP66 waterproof rating and high efficiency.
8.The blades are made of engineering plastic steel, Nylon 66 + 30% fiber, providing acid and alkali resistance, deformation resistance, and excellent rigidity.
9.one-piece molding pp material, alkali resistance and high-temperature durability.
1.High-strength X-shaped stand with excellent structural grip ensures motor stability and vibration-free fan operation.
2.The wheel disc is made of aluminum alloy material, providing rust resistance and enhanced safety.
3.The front metal protective grille enhances safety levels.
4.The stand is made of aluminum alloy , offering rust and corrosion resistance, durability, and aesthetics. 5.It also prevents rainwater from flowing into the motor through the stand.
6.The entire unit uses 304 stainless steel screws.
7.Equipped with an EC motor featuring an IP66 waterproof rating and high efficiency.
8.The blades are made of engineering plastic steel, Nylon 66 + 30% fiber, providing acid and alkali resistance, deformation resistance, and excellent rigidity.
9.one-piece molding pp material, alkali resistance and high-temperature durability.
Product Name:57-Inch 3-Blade EC Motor Industrial Duct Exhaust Fan
Model Number:E57C3P
Rated Voltage:Three-phase / 220V / 60Hz / 6.8A
Motor Parameters:2.9HP/14P/F-Class/IP66
Power Consumption:2466W
Fan Speed Control Compatible with Speed Controller
Maximum Speed:725 RPM
Maximum Airflow:70,000 m³/h
Noise Level:≦84 dB
Product Dimensions:175cm × 175cm × 180cm
Weight:120kg
Model Number:E57C3P
Rated Voltage:Three-phase / 220V / 60Hz / 6.8A
Motor Parameters:2.9HP/14P/F-Class/IP66
Power Consumption:2466W
Fan Speed Control Compatible with Speed Controller
Maximum Speed:725 RPM
Maximum Airflow:70,000 m³/h
Noise Level:≦84 dB
Product Dimensions:175cm × 175cm × 180cm
Weight:120kg
